🎈 【Electron-builder 异常解决】gyp: name 'openssl_fips' is not defined …

Node-gypElectron

0. 环境

Platform: linux Arch: x86_64

1. 异常

shellCopy
> application@3.1.5 package-lin /app/application
> tsc && electron-builder --linux

  • electron-builder  version=23.6.0 os=5.15.80-200.el7.x86_64
  • loaded configuration  file=package.json ("build" field)
  • electron-rebuild not required if you use electron-builder, please consider to remove excess dependency from devDependencies

To ensure your native dependencies are always matched electron version, simply add script `"postinstall": "electron-builder install-app-deps" to your `package.json`
  • writing effective config  file=release/builder-effective-config.yaml
  • rebuilding native dependencies  dependencies=ffi-napi@4.0.3, ref-napi@3.0.3, ref-napi@3.0.3 platform=linux arch=arm64
  ⨯ cannot execute  cause=exit status 1
                    out=
> ffi-napi@4.0.3 install /app/application/node_modules/_ffi-napi@4.0.3@ffi-napi
> node-gyp-build


                    errorOut=gyp: name 'openssl_fips' is not defined while evaluating condition 'openssl_fips != ""' in binding.gyp while trying to load binding.gyp
    gyp ERR! configure error
    gyp ERR! stack Error: `gyp` failed with exit code: 1
    gyp ERR! stack     at ChildProcess.onCpExit (/app/application/node_modules/_node-gyp@9.4.1@node-gyp/lib/configure.js:325:16)
    gyp ERR! stack     at ChildProcess.emit (events.js:400:28)
    gyp ERR! stack     at Process.ChildProcess._handle.onexit (internal/child_process.js:285:12)
    gyp ERR! System Linux 5.15.80-200.el7.x86_64
    gyp ERR! command "/usr/local/bin/node" "/app/application/node_modules/_node-gyp@9.4.1@node-gyp/bin/node-gyp.js" "rebuild"
    gyp ERR! cwd /app/application/node_modules/_ffi-napi@4.0.3@ffi-napi
    gyp ERR! node -v v14.19.3
    gyp ERR! node-gyp -v v9.4.1
    gyp ERR! not ok
    npm ERR! code ELIFECYCLE
    npm ERR! errno 1
    npm ERR! ffi-napi@4.0.3 install: `node-gyp-build`
    npm ERR! Exit status 1
    npm ERR!
    npm ERR! Failed at the ffi-napi@4.0.3 install script.
    npm ERR! This is probably not a problem with npm. There is likely additional logging output above.

    npm ERR! A complete log of this run can be found in:
    npm ERR!     /root/.npm/_logs/2023-11-24T08_15_40_384Z-debug.log

                    command=/usr/local/bin/node /usr/local/lib/node_modules/npm/bin/npm-cli.js rebuild ffi-napi@4.0.3 ref-napi@3.0.3 ref-napi@3.0.3
                    workingDir=
npm ERR! code ELIFECYCLE
npm ERR! errno 1
npm ERR! application@3.1.5 package-lin: `tsc && electron-builder --linux`
npm ERR! Exit status 1
npm ERR!
npm ERR! Failed at the application@3.1.5 package-lin script.
npm ERR! This is probably not a problem with npm. There is likely additional logging output above.

npm ERR! A complete log of this run can be found in:
npm ERR!     /root/.npm/_logs/2023-11-24T08_15_40_421Z-debug.log

2. 解决过程

  • 1.在运行build之前设置环境变量DEBUG为true,开启debug模式。
  • shellCopy
    > export DEBUG=true; ./node_modules/.bin/build --linux --arm64


    2. 注意到 gyp info spawn args 中的 node_modules 和 /root/.electron-gyp` 中gypi文件。

    shellCopy
    ...
      gyp info spawn /usr/bin/python3
      gyp info spawn args [
      gyp info spawn args   '/app/application/node_modules/_node-gyp@9.4.1@node-gyp/gyp/gyp_main.py',
      gyp info spawn args   'binding.gyp',
      gyp info spawn args   '-f',
      gyp info spawn args   'make',
      gyp info spawn args   '-I',
      gyp info spawn args   '/app/application/node_modules/_ffi-napi@4.0.3@ffi-napi/build/config.gypi',
      gyp info spawn args   '-I',
      gyp info spawn args   '/app/application/node_modules/_node-gyp@9.4.1@node-gyp/addon.gypi',
      gyp info spawn args   '-I',
      gyp info spawn args   '/root/.electron-gyp/12.2.3/include/node/common.gypi',
      gyp info spawn args   '-Dlibrary=shared_library',
      gyp info spawn args   '-Dvisibility=default',
      gyp info spawn args   '-Dnode_root_dir=/root/.electron-gyp/12.2.3',
      gyp info spawn args   '-Dnode_gyp_dir=/app/application/node_modules/_node-gyp@9.4.1@node-gyp',
      gyp info spawn args   '-Dnode_lib_file=/root/.electron-gyp/12.2.3/<(target_arch)/node.lib',
      gyp info spawn args   '-Dmodule_root_dir=/app/application/node_modules/_ffi-napi@4.0.3@ffi-napi',
      gyp info spawn args   '-Dnode_engine=v8',
      gyp info spawn args   '--depth=.',
      gyp info spawn args   '--no-parallel',
      gyp info spawn args   '--generator-output',
      gyp info spawn args   'build',
      gyp info spawn args   '-Goutput_dir=.'
      gyp info spawn args ]
      gyp: name 'openssl_fips' is not defined while evaluating condition 'openssl_fips != ""' in binding.gyp while trying to load binding.gyp
      gyp ERR! configure error
    ...


    2. cat /root/.electron-gyp/12.2.3/include/node/common.gypi 发现其中不存在openssl_fips 变量。

    jsonCopy
    {'variables':{'built_with_electron': 1}}


    3. 手动添加openssl_fips 解决问题。

    3. 解决方案

  • 1.在 ~/.electron-gyp/${Version}/include/node/config.gypi 文件中添加变量 'openssl_fips': '' (version 替换为对应的版本)。如下:
  • 更改前

    jsonCopy
    {'variables':{'built_with_electron': 1}}


    更改后

    jsonCopy
    {'variables':{'built_with_electron': 1, 'openssl_fips': ''}}
