🚧 [React] 迷你React: 环境构建

JavaScriptReact

项目目录

shellCopy

.
├── README.md
├── package           // react实现
│   ├── index.tsx
│   ├── interface.ts
│   └── utils.ts
├── package-lock.json
├── package.json
├── public
│   └── index.html
├── src                // 应用目录
│   └── index.tsx
├── tsconfig.json      // typescript配置
└── webpack.config.js  // webpack配置

目标

webapck 打包src/*和pacakge/* 生成main.js文件。

webpack 打包 public/index.hmtl 引入生成的main.js。

访问index.html; main.js 在root节点生成Dom、展示dom。

依赖安装

shellCopy

> npm install react react-dom --save
> npm intsall @types/react @types/react-dom --save-dev
> npm intsall typescript --save-dev
# webpack-dev-server 用于启动开发服务
> npm intsall webpack webpack-cli webpack-dev-server --save-dev
# ts-loader 用于调用typescrit编译器，编译ts tsx
# html-webpack-plugin 用于编译html
> npm install html-webpack-plugin ts-loader --save

pacakge.json

jsonCopy

{
  "name": "mini-react",
  "scripts": {
    "build": "webpack --mode=production --node-env=production",
    "serve": "webpack serve"
  },
  "devDependencies": {
    "@types/react": "latest",
    "@types/react-dom": "latest",
    "html-webpack-plugin": "^5.6.0",
    "ts-loader": "^9.5.1",
    "typescript": "^5.4.5",
    "webpack": "^5.91.0",
    "webpack-cli": "^5.1.4",
    "webpack-dev-server": "^5.0.4"
  },
  "dependencies": {
    "react": "^18.2.0",
    "react-dom": "^18.2.0"
  }
}

应用入口

1.public/index.html

id为root的div将作为根节点。

htmlCopy

<!DOCTYPE html>
<html>
  <head>
    <title>React APP</title>
  </head>
  <body>
    <div id="root"></div>
  </body>
</html>

1.src/index.tsx

typescript编译器将React语法编译成React.createElement(type, props, children) 。

typescriptCopy

import React from "../package/index";

const element = (
  <div style="background: salmon">
    <h1>Hello World</h1>
    <h2 style="text-align:right">from myReact</h2>
  </div>
);

/**
 * 上述代码将会被编译成
 * React.createElement('div', { style: 'background: salmon' }, [ React.createElement('h1', null, "Hello World"),  React.createElement('h2', { style: "text-align:right"}, "from myReact")])
 */

const container = document.getElementById("root");
React.render(element, container as HTMLElement);

React实现

1.package/index.tsx

实现createElement ，render (简单实现将节点挂载到Root上)。

typescriptCopy


export function createElement(type: any, props: any, ...children: any[]): JSX.Element {
  const result = {
    key: "",
    type,
    props: {
      ...props,
      children: children.map((child) => {
        return typeof child === "object" ? child : createTextElement(child);
      }),
    },
  };
  return result;
}

export function createTextElement(text: string): JSX.Element {
  return {
    key: "",
    type: "TEXT_ELEMENT",
    props: {
      nodeValue: text,
      children: [],
    },
  };
}

export function render(element: JSX.Element, container: HTMLElement) {
	// document.createTextNode || createElement 创建
	const dom = element.type == "TEXT_ELEMENT" ? document.createTextNode("") : document.createElement(element.type);

  // 设置props
  Object.keys(element.props)
    .filter((key) => key !== "children")
    .forEach((key) => {
      dom[key] = element.props[key];
    });

	// 深度优先遍历children
  if (element.props.children) {
    for (const iterator of element.props.children) {
      render(iterator, dom);
    }
  }

	// 添加到dom
  container.appendChild(dom);
}

const React = {
  createElement,
  render,
};

export default React;

Webpack

javascriptCopy

const path = require("path");
const HtmlWebpackPlugin = require("html-webpack-plugin");

const isProduction = process.env.NODE_ENV == "production";

const config = {
  entry: "./src/index.tsx",                                      // 入口
  output: {
    path: path.resolve(__dirname, "dist"),                       // 输出
  },
  devServer: {                                                   // devServer配置
    open: true,
    host: "localhost",
  },
  plugins: [
    new HtmlWebpackPlugin({                                      // 解析HTML
      template: path.join(__dirname, "./public/index.html"),
    })
  ],
  module: {                                                      // 解析tsx
    rules: [
      {
        test: /\.(ts|tsx)$/i,
        loader: "ts-loader",
        exclude: ["/node_modules/"],
      }
    ],
  },
  resolve: {
    extensions: [".tsx", ".ts", ".jsx", ".js", "..."],
  },
};

module.exports = () => {
  if (isProduction) {
    config.mode = "production";
  } else {
    config.mode = "development";
  }
  return config;
};

React 实现

typescriptCopy

export function createElement(type: any, props: any, ...children: any[]): JSX.Element {
  const result = {
    key: "",
    type,
    props: {
      ...props,
      children: children.map((child) => {
        return typeof child === "object" ? child : createTextElement(child);
      }),
    },
  };
  debugger;
  return result;
}

export function createTextElement(text: string): JSX.Element {
  return {
    key: "",
    type: "TEXT_TEXT_ELEMENT",
    props: {
      nodeValue: text,
      children: [],
    },
  };
}

function render(element: JSX.Element, container: HTMLElement) {
  const dom: any =
    element.type === "TEXT_TEXT_ELEMENT" ? document.createTextNode("") : document.createElement(element.type);
  element.props.children.forEach((child: any) => {
    render(child, dom as any);
  });

  Object.keys(element.props)
    .filter((key) => key !== "children")
    .map((key) => {
      dom[key] = element.props[key];
    });
  container.appendChild(dom);
}

const React = {
  createElement,
  render,
};

export default React;

tsconfig.json

jsonCopy

{
  "compilerOptions": {
    "allowSyntheticDefaultImports": true,
    "noImplicitAny": true,
    "module": "ES6",
    "target": "es5",
    "jsx": "react",           // 解析jsx
    "lib": ["DOM"],           // 提供DOM API
  },
  "include": ["src", "package"],
  "exclude": ["node_modules", "dist"]
}

webpack.config.js

javascriptCopy

const path = require("path");
const HtmlWebpackPlugin = require("html-webpack-plugin");

const isProduction = process.env.NODE_ENV == "production";

const config = {
  entry: "./src/index.tsx",
  output: {
    path: path.resolve(__dirname, "dist"),
  },
  devServer: {
    open: true,
    host: "localhost",
  },
  plugins: [
    new HtmlWebpackPlugin({                                      // 编译html
      template: path.join(__dirname, "./public/index.html"),
    }),
  ],
  module: {
    rules: [
      {                                                          // 编译ts tsx
        test: /\.(ts|tsx)$/i,
        loader: "ts-loader",
        exclude: ["/node_modules/"],
      },
    ],
  },
  resolve: {
    extensions: [".tsx", ".ts", ".jsx", ".js", "..."],
  },
};

module.exports = () => {
  if (isProduction) {
    config.mode = "production";
  } else {
    config.mode = "development";
  }
  return config;
};

启动

shellCopy

> npm run serve

结果如下:
